P. 93
COMPLETE AIR SPRING
www.smarttech.com.tr
Order No 60030022 ST 836.CS08 Air Spring
OEM References Cross References
Ø273
150
80
3xM10x1.5
M22x1.5
33 110
ST 836.CS08 5
h : 277 155 70
M16x2 6H
130
Ø230
Weight (Kg): 7,26 QIP: 36
Order No 60030023 ST 836.CS09 Air Spring
OEM References Cross References
DAF 1 622 849 Contitech 836 N P09
DAF 1 697 683 Firestone 1T17AR-4.5
Firestone W01-M58-8364
Airtech 3836-09 C
Ø258
15 22 3XM10x1.5 6G
2xM16x1.5 6H
28
5
45 110
5
ST 836.CS09
75
270 85 70
155
M16x2 6H
133
Ø225
Weight (Kg): 7,14 QIP: 36
Order No 60030024 ST 836.CS10 Air Spring
OEM References Cross References
DAF 1 794 420 Contitech 836 N P10
Phoenix 1 DF 23 A-4
Firestone 1T17AR-4.5
Firestone W01-M58-8368 15 22 Ø258
Goodyear 1R12-849 70.02
Goodyear 566-24-3-548 2xM10x1.5 6G
Vibracoustic RML7947C10
33 55
ST 836.CS10 M22x1.5 6H 55
270
157.5
M16x2 6H
130
Ø225
Weight (Kg): 7,18 QIP: 36
Bolt Or Stud Threaded Hole Combination Stud Air Inlet 93
